LUMAPRO

LumaPro 100 ft. Extension Cord Reel; 120 VAC, Yellow Reel Color

Hover over image to magnify
Cord Reel,Outlet,100Ft,SO12/3,
PI_Asset_973073
Cord Reel,Outlet,100Ft,SO12/3,
PI_Asset_973073
Double tap image to magnify
Cord Reel,Outlet,100Ft,SO12/3,
9292666_1
Cord Reel,Outlet,100Ft,SO12/3,
9292666_1

#929266-6Pkg Qty: 1

$627.66 pkg | $627.66 ea

Out of Stock

Shipping to 43085
Backordered, expected to arrive between Tue. Apr 08 - Tue. Apr 22.
|

Technical Specifications

Key Specifications
Brand
LUMAPRO
NEC Cord Designation
SO
Cord Color
Yellow
Number of Conductors
3
Cord Included
Yes
Number of Outlets
4
Cord Length
100 ft.
Overall Depth
10-1/2 in.
Enclosed Reel
No
Overall Height
17-1/2 in.
Enclosure Rating
Not Rated
Overall Width
13-3/8 in.
Feeder Cord Ending
Grounding Plug
Package Quantity
1
Feeder Cord Ending NEMA Configuration
5-15R
Reel Color
Yellow
Feeder Cord Length
100 ft.
Reel Material
Steel
Holds
100 ft. of 12/3
Reel Mounting
Hand Hold
Indoor/Outdoor
Indoor
Shipping Weight
31.86 lb.
Item
Extension Cord Reel
Temperature Range
-30 deg. F to 140 deg. F
Maximum Amps
13
Voltage
120 VAC
Mfr. Part Number
22M975
Wire Size
12 AWG
General
Feeder Cord Ending Configuration
NEMA 5-15R
Retractable Cord Ending
Quad Receptacle On Reel
Gauge/Conductor - Ext. Cords and Outlet Strips
12/3
Retractable Cord Ending Configuration
NEMA 5-15P
Grade - Ext. Cords and Outlet Strips
General Purpose
Standards
cETLus
Includes
Carry Handle with Molded Grip, Circuit Breaker
Voltage - Ext. Cords and Outlet Strips
120VAC
Includes Cord
Yes
Winding Method
Hand Operated
Max. Amps - Ext. Cords and Outlet Strips
13.0

Product Description

Hand-winding cord reels have a handle or knob that is turned by hand to wind the extension cord around the spool when not in use. They are typically used with lightweight or shorter cords in retail or small business applications, where rewinding the cord manually doesn't take too much effort. These reels hold extension cords that supply temporary power to devices located some distance away from an electrical outlet.

Standard cord reels are spools that hold extension cords to provide access and storage while protecting them from tangling, kinking, and other damage. The cord can be extended to exactly the length needed to power equipment located at a distance from a power source. Self-retracting and motor-driven cord reels automatically wind extended cord back on the reel, while hand-winding cord reels have a handle or knob for winding the cord manually. These cords can be mounted out of the way in a central location, such as on a wall or ceiling, to keep a workspace organized and help reduce tripping hazards. They are commonly used in retail, commercial, and manufacturing applications, including pressure washing, landscaping and ground maintenance, and service garages.
