Home All Products Electrical Plugs & Connectors Straight Blade Plugs SKU: 932325-5

Hubbell Wiring Device-Kellems 15A Commercial Grade Straight Blade Plug, Gray; NEMA Configuration: 5-15P

Name: Hubbell Wiring Device-Kellems 15A Commercial Grade Straight Blade Plug, Gray; NEMA Configuration: 5-15P
Brand: HUBBELL WIRING DEVICE-KELLEMS
SKU: 9323255
Price: 18.09 USD
Availability: InStock

Hover over image to magnify

Double tap image to magnify

#932325-5Pkg Qty: 1

$18.09 pkg | $18.09 ea

In Stock

Shipping to 43085

Expected to arrive Tue. Apr 01.

Technical Specifications

Key Specifications

Amps

15 A

Maximum Wire Size

12 AWG

Antimicrobial

Mfr. Part Number

HBL5965VGY

Brand

HUBBELL WIRING DEVICE-KELLEMS

Minimum Operating Temperature

-40 °C

Color Family

Gray

Minimum Wire Size

18 AWG

Connection Orientation

Straight

NEMA Configuration - Plugs & Connectors

5-15

Cord Size

0.220 in. to 0.660 in.

Number of Blades

Corrosion Resistant

Yes

Number of Poles

Current Rating

15 A

Number of Wires

Description

Valise, Grounding

Package Quantity

Grade

Commercial

Phase

Single

Grounding

Grounded

Polarized

Yes

Horsepower

2 hp

Shipping Weight

.1 lb.

Housing Color

Gray

Standards

CSA Certified C22.2 No. 42 File 280C, NEMA WD-6, UL 498 File E1706

Housing Material

Polycarbonate

Sub-Category

Plugs

IP Rating

IP20

UL 94 Flammability Rating

Insulation Material

Nylon

Voltage

125V AC

Item

Straight Blade Plug

Wire Connection Type

Screw Terminals

Material

Nylon

Wiring Style

Hinged

Maximum Operating Temperature

75 °C

General

Amps - Plugs and Receptacles

15 A

NEMA Plug Configuration - Plugs and Receptacles

5-15P

Grade - Plugs and Receptacles

Commercial

Phase - Plugs and Receptacles

0.5

Voltage - Plugs and Receptacles

125V AC

Product Description

NEMA Straight-Blade Plugs and Connectors CSA Certified.

Valise® 1-pc. nylon construction with load-bearing locking lugs and 2 assembly screws provide a quick, secure assembly. Large, easy-to-wire terminal clamps feature a bundling effect on conductors. Powerful offset cord grip resists conductor slippage and prevents strain on terminations.
