ASHCROFT Digital Pressure Gauge: Test Pressure Gauge, 0 to 600 psi, Std Gauge, 3 in Dial, Bottom

Hover over image to magnify
Gauge,Pressure,Digital
Gauge,Pressure,Digital

#939886-8 | Pkg Qty: 1

$438.73 pkg | $438.73 ea

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Battery Run Time
400 hr.
Gauge Primary Range Units
psi
Brand
ASHCROFT
Gauge Sensor Material
Stainless Steel
Burst Pressure
4800 psi
Gauge Socket Material
316 Stainless Steel
Calibration Certificate Included
No
Hazardous Location Rating
Not Rated
Display
LCD
Item
Digital Test Pressure Gauge
Gauge Accuracy
±0.25%
Mfr. Part Number
302074SD02L600BL
Gauge Application
Hydraulics, Measurement and Validation, Mobile Equipment, OEM Applications, Pneumatics, Pumps, Test and Measurement, Weighing Systems
Mfr. Warranty Length
1 yr.
Gauge Case Color
Gray
Mounting Type
Stem-Mount
Gauge Case Material
Stainless Steel
Non-Sparking
No
Gauge Connection Location
Bottom
Number of Digits
5
Gauge Connection Size
1/4 in.
Operating Temperature Range
14 deg. F to 140 deg. F
Gauge Connection Type
MNPT
Package Quantity
1
Gauge Lens Material
Polyester
Pressure Range
0 to 600
Gauge Nominal Dial Size
3 in.
Series
2074
Gauge Panel Mountable
No
Shipping Weight
.85 lb.
General
Auto-Shutoff
Yes
Languages
English
Auto-Shutoff Time
2 min, 5 min, 15 min, 30 min
Manufacturer Warranty Length
1 yr
Backlit Screen
Yes
Memory Features
Min/Max
Bar Graph
10 Segments
Nominal Dial Size
3 in
Case Construction
Corrosion Resistant
Number of Display Digits
5
Case Depth
1.7 in
Pressure Gauge Type
Test Pressure Gauge
Case Diameter
3.34 in
Pressure Range Type
Pressure
Case Shape
Round
Primary Display Range
0 to 600
Data Update Frequency
100 msec, 200 msec, 500 msec, 1 sec
Primary Display Units
psi
Digit Height
0.6 in
Primary Range
0 to 600
Digital Gauge Accuracy
+/-0.25% Full Scale
Primary Units
psi
Digital Gauge Display Units
bar, ft wc, in Hg, kg/sq cm, kPa, mbar, MPa, psi
Process Connection
1/4 in NPT Male
Digital Pressure and Vacuum Gauge Type
Digital Pressure Gauge
Process Connection Gender
Male
Display Range
0 to 10,000 mbr, 0 to 25 bar, 0 to 25 Mpa, 0 to 2,500 kpa, 0 to 600 in Hg, 0 to 600 psi
Process Connection Location
Bottom
Display Screen Type
LCD
Process Connection Size
1/4 in
Gauge Mounting Type
Stem-Mount
Process Connection Type
NPT
Gauge Wetted Parts
Stainless Steel
Sensor Material
Stainless Steel
IP/NEMA Rating
IP65
Sensor Type
Diaphragm
Includes
Battery and Instructions
Test Pressure Gauge Type
Test Pressure Gauge
Includes Batteries
Yes
Weatherproof
Yes
Includes Rubber Boot
Yes
With Calibration Certificate
Standard Gauge

Product Description

Digital Test Pressure Gauge, Accuracy +/-0.25 Percent, Gauge Case Material Stainless Steel, Nominal Dial Size 3 in, Lens Material Polyester, IP/NEMA Rating IP65, Hazardous Location Rating Not Rated, Sensor Material Stainless Steel, Socket Material 316 Stainless Steel, Sensor Type Diaphragm, Process Connection Type NPT, Display Units bar, ft wc, in Hg, kg/sq cm, kPa, mBar, Mpa, psi, Process Connection Gender Male, Battery Type (2) AA Batteries, Process Connection Location Bottom
