Molded Case Circuit Breaker: 50 A Amps, 65kA at 240/277V AC, Fixed, ABC, Load Side Lug, Std

Name: Molded Case Circuit Breaker: 50 A Amps, 65kA at 240/277V AC, Fixed, ABC, Load Side Lug, Std
Brand: EATON
SKU: 9398611
Price: 1665.39 USD
Availability: InStock

Hover over image to magnify

Double tap image to magnify

#939861-1Pkg Qty: 1

$1,665.39 pkg | $1,665.39 ea

In Stock

Shipping to 43085

Ships from supplier. Expected to arrive on or before Mon. Apr 21.

Technical Specifications

Key Specifications

AC Voltage Rating

600VAC

Maximum Air Rating

65kA at 240/277VAC

Amperage

50 A

Maximum Wire Size

1/0 AWG

Amps

50 A

Mfr. Part Number

FD3050

Brand

EATON

Minimum Wire Size

1/0 AWG

Circuit Breaker Type

Standard

Mounting

Free Standing

DC Voltage Rating

250VDC

Number of Poles

Depth

3.38 in.

Package Quantity

For Use With

Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse

Phase

Three

Frame Size

225A/F

Phase Connection

ABC

Height

6 in.

Series

High Amp Trip Setting

225 A

Shipping Weight

4.3 lb.

Instantaneous Trip

Fixed

Terminal Connection

Load Side Lug

Item

Molded Case Circuit Breaker

Trip Type

Thermal Magnetic

Low Amp Trip Setting

15 A

Width

4.13 in.

General

Circuit Breaker Actuator

Toggle

Min. Operating Temp.

-4°F

Max. Operating Temp.

158°F

Product Description

FD-frame Eaton molded case circuit breakers are rated up to 225A and 600VAC and interrupt excessive current flows to protect devices from electrical damage. They're typically used with Eaton, Allen-Bradley, and Rockwell Automation motor control centers. Their current-carrying parts, mechanisms, and trip devices are contained in a molded case.
