Flange Bolts: Standard, Alloy Steel, Grade E9, Plain, 4 in lg, Partially Threaded, Inch

Hover over image to magnify
Hex Cap Screw,1-8x4
Hex Cap Screw,1-8x4
Double tap image to magnify
Hex Cap Screw,1-8x4
Hex Cap Screw,1-8x4

#938561-5Pkg Qty: 1

$57.45 pkg | $57.45 ea

In Stock

Shipping to 43085
Expected to arrive Wed. Apr 02.
|

Technical Specifications

Key Specifications
Basic Material
Steel
Meets/Exceeds
ASTM A574, IFI-115
Brand
APPROVED SUPPLIER
Mfr. Part Number
725218G
Class
3A
Overall Length
4 in.
Fastener Industry Standards
ASTM A574, IFI-115
Package Quantity
1
Fastener Thread Direction
Right Hand
Proof Load
140,000 PSI
Finish
Plain
Rockwell Hardness
HRC37
Flange Bolt Head Type
12-Point
Screw Size
1 in.
Flange Bolt Thread Style
Partially Threaded
Shipping Weight
1.1 lb.
Flange Diameter
1-1/2 in.
Thread Direction
Right Hand
Grade
A574
Thread Length
1-1/4 in.
Head Height
1 in.
Thread Size
1"-8
Head Width
1 in.
Thread Type
Coarse
Item
Flange Bolts
Type
High Strength
Length Under Head
4 in.
General
Maximum Flange Diameter
1 1/2 in
Nut Width
1 in
Minimum Thread Length
2-1/2 in.

Product Description

Flange Bolts, Basic Material Steel, Material Grade Alloy Steel, Fastener Finish Plain, Dia./Thread Size 1 In.-8, Fastener Length 4 in, Fastener Thread Direction Right Hand, Fastener Thread Type UNC (Coarse), Fastener Thread Style Partially Threaded, Fastener Industry Standards ASTM A574, IFI-115, Thread Length 1 1/4 in, Head Height 1 in, Head Width 1 in, Flange Dia. 1 1/2 in, Proof Load 140,000 psi, Tensile Strength 170,000 psi, Rockwell Hardness HRC37
