LEESON

Leeson Air Compressor Motor: Capacitor-Start, 5 HP, 3,600 Nameplate RPM, 208-230V AC, R56Y Frame

Hover over image to magnify
Air Compressor Motor,5 Hp,3600
Air Compressor Motor,5 Hp,3600
Double tap image to magnify
Air Compressor Motor,5 Hp,3600
Air Compressor Motor,5 Hp,3600

#937813-1Pkg Qty: 1

$597.09 pkg | $597.09 ea

In Stock

Shipping to 43085
Expected to arrive Fri. Mar 28.
|

Technical Specifications

Key Specifications
Brand
LEESON
Motor Design
Capacitor-Start
Duty Cycle
Continuous
Nameplate RPM
3600
Frame
R56Y
Overall Length
14 9/16 in.
Full Load Amps
22
Pack Quantity
1
Hz
60
Phase
Single
Item
Air Compressor Motor
Shaft Length
2-1/4 in.
Length Less Shaft
12-1/4 in.
Shipping Weight
48.3 lb.
Mfr. Part Number
B384
Voltage
208-230 VAC
Mfr. Warranty Length
18 mo
General
HP
5
Motor Shaft Design
Keyed
Includes
Key
Motor Shaft Rotation
CCWSE
Ins. Class
B
Motor Thermal Protection
Manual
Max. Ambient Temp.
40 °C
No. of Speeds
1
Motor Application
Air Compressor
Nominal Efficiency
81.2 %
Motor Bearings
Ball
RPM Range
3,001-3,600
Motor Enclosure Design
Open Dripproof
Shaft Dia.
7/8 in
Motor Frame Material
Steel
Standards
CSA, UL
Motor Mounting Position
Horizontal
Usable @ 208V
Yes
Motor Mounting Type
Rigid Base
Voltage Compatibility
208-230V AC
Motor Service Factor
1.15

Product Description

Air Compressor Motor, Single Phase, Motor Design Capacitor-Start, 5 HP, Nameplate RPM 3, 600, No. of Speeds 1, Voltage 208-230V AC, Full Load Amps 22.0, R56Y Frame, 60 Hz, Motor Service Factor 1.15, Motor Thermal Protection None, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CWSE, Motor Enclosure Design Open Dripproof, Motor Mounting Type Rigid Base, Motor Mounting Position Horizontal, Motor Frame Material Steel, Shaft Dia. 7/8 in

Item Barcode

9378131
