Eaton Manual Motor Protector, 25.00 to 32.00A Amps AC, Rotary Knob, 1.77" Width

Name: Eaton Manual Motor Protector, 25.00 to 32.00A Amps AC, Rotary Knob, 1.77" Width
Brand: EATON
SKU: 9377148
Price: 356.28 USD
Availability: InStock

Hover over image to magnify

Double tap image to magnify

#937714-8Pkg Qty: 1

$356.28 pkg | $356.28 ea

In Stock

Shipping to 43085

Expected to arrive Tue. Mar 25.

Technical Specifications

Key Specifications

Amps AC

25.00 to 32.00A

Number of Poles

Brand

EATON

Pack Quantity

Depth

3.46 in.

Shipping Weight

.69 lb.

Frame Size

Frame B

Starter Type

Manual

Height

3.66 in.

Type

Rotary

Mfr. Part Number

XTPR032BC1

Width

1.77 in.

General

HP @ 1 Phase - 115V

2 hp

HP @ 3 Phase - 480V

20 hp

HP @ 1 Phase - 230V

5 hp

HP @ 3 Phase - 575V

30 hp

HP @ 3 Phase - 200V

7 1/2 hp

NEMA Size

Frame B

HP @ 3 Phase - 230V

Operator

Rotary Knob

HP @ 3 Phase - 240V

10 hp

Standards

CCC, CSA Certified, IEC

HP @ 3 Phase - 460V

Product Description

IEC Manual Motor Starters

Bimetallic thermal overload relays 3-pole Trip test Phase loss sensitivity protection 35mm DIN rail mounting Class 10 overload protection Eaton XT/PKZ Series features push-button or rotary On/Off manual disconnect with lockout provision. Available with screw terminals. Built-in heater and magnetic trip protect motor. Suitable for applications requiring manual starting and stopping of motors. UL 508 Type E and F rated with use of line side adapter. UL Listed and CSA Certified. Meet CE and IEC standards.
