SQUARE D
Square D 120V AC, 8-Pin Flange Mount Relay; Flange Location: Side, AC Contact Rating: 12A @ 240V
Hover over image to magnify
#936729-8 | Pkg Qty: 1
$46.11 pkg | $46.11 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Base Type
Square
HP @ 240 V
1/2 hp
Brand
SQUARE D
Item
Flange Mount Relay
Coil VA Rating
2-1/2
Mfr. Part Number
8501KFR12V20
Coil Volts
120 VAC
Mounting
Side
Contact Form
DPDT
Number of Poles
2
Contact Material
Silver Cadmium Oxide
Pack Quantity
1
Contact Rating
12A @ 240 VAC/28 VDC
Pins
8
Electrical Connection
0.187 in. Push On Terminal
Shipping Weight
.3 lb.
Flange Location
Side
Status Indicator
No
HP @ 120 V
1/3 hp
General
AC Contact Rating - Relay
12A @ 240V
HP @ 240V
1/2 hp
Body Depth - Relay
1.4 in
Mounting - Relay
Side Flange
Body Height - Relay
1.9 in
Number of Pins - Relay
8
Body Width - Relay
1.4 in
Overall Height - Relay
2.75 in
Contact Form - Relay
DPDT
Power Consumption - Relay
2.5 VA
DC Contact Rating - Relay
12A @ 28V
Standards
CE Marked, CSA Certified
HP @ 120V
1/3 hp
Product Description
Flange Mount Relay, Coil Volts 120V AC, AC Contact Rating - Relay 12A at 240V, DC Contact Rating - Relay 12A at 28V, Number of Pins - Relay 8, Contact Form - Relay DPDT, Mounting - Relay Side Flange, Power Consumption - Relay 2.5 VA, Contact Material Silver Cadmium Oxide, Status Indicator No, Electrical Connection 0.187 in Push On Terminal
Item Barcode
Flange Relay,120VAC,8 Pins,12A
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 2DR88 | |
 | UNSPSC CODES | 39122325 | |
 | VMRS (ATA) CODES | 053-006-009 |
