BIG ASS FANS

Big Ass Fans 72", Standard-Duty Industrial Fan, Non-Oscillating, Mobile, Floor, 110-125 VAC

Hover over image to magnify
Portable Floor Fans,6.5 Ft.
PI_Asset_1495718
Portable Floor Fans,6.5 Ft.
PI_Asset_1495718
Double tap image to magnify
Portable Floor Fans,6.5 Ft.
699W08_1
Portable Floor Fans,6.5 Ft.
699W08_1

#935452Pkg Qty: 1

$9,578.23 pkg | $9,578.23 ea
This item requires special shipping, additional charges may apply.

In Stock

Shipping to 43085
Ships from supplier. Expected to arrive on or before Thu. Apr 10.
|

Technical Specifications

Key Specifications
Air Flow
21,971 cfm
Motor Insulation
Class F
Amps
4.7
Mounting Location
Floor
Bearing Type
Double Sealed Ball
NEMA Plug Configuration
5-15P
Blade Diameter
72 in.
Number of Blades
6
Blade Material
Aluminum
Number of Conductors
0
Brand
BIG ASS FANS
Oscillating
No
Drive Type
Direct
Package Quantity
1
Duty
Standard Duty
Phase
1
Guard Material
Steel
RPM
291
Hz
50/60 Hz
Shipping Weight
557 lb.
Item
Industrial Fan
Sound Level
43 dBA
Mfr. Part Number
F-BJ1-0601
Standards
UL, ETL
Mobile/Stationary
Mobile
Voltage
110 to 125V AC
Motor Enclosure
Open Dripproof
Wheel Material
Rubber
General
Air Velocity @ 10 Ft.
640 fpm
Fan Overall Type
Commercial/Industrial
Air Velocity @ 40 Ft.
430 fpm
Fan Power Source
Plug-In
Air Velocity @ 60 Ft.
340 fpm
Max. Ambient Temp.
122 Degrees F
Air Velocity @ 80 Ft.
290 fpm
Oscillation
Non-Oscillating
Environmental Applications
Industrial
Speed Controllable - Fans
Yes
Fan Accessory Finish
Powder Coated
Wheel Dia.
8 in
Fan Mounting Location
Floor
Wire Guard Finish
Powder Coated

Product Description

Standard-duty industrial mobile and stationary floor fans cool heavy manufacturing areas and other dusty or dirty environments. Compared to light-duty industrial fans, these standard-duty fans are made of heavier-gauge materials, have a higher-horsepower motor, and feature more-robust motor bearings for a longer life.

Industrial mobile and stationary floor fans sit close to the ground to resist tipping over, even when bumped, while providing a powerful stream of air at floor level. These air circulators are often used for spot cooling workstations or production lines and for general cooling in manufacturing plants, warehouses, and shipping operations. Made of heavy-gauge materials suitable for daily use, these axial fans have a powerful motor that drives the fan blades to move large volumes of air and feature high-performance bearings for a long life. A guard encloses the fan blades to help protect them from damage and prevent injuries from accidental contact. Mobile floor fans have wheels, so they can be rolled from one location to another as cooling needs change. Stationary floor fans are used in applications where fans don't need to be frequently relocated, but they are generally light enough to carry between locations.

Item Barcode

9354520
Portable Floor Fans,6.5 Ft.

For more product information by email, click here
