CJT KOOLCARB

Cjt Koolcarb Taper Length Drill Bit, Drill Bit Size 49/64", Drill Bit Point Angle 125, 4 Facet Point

Hover over image to magnify
Taper Length Drill Straight
Taper Length Drill Straight
Cjt Koolcarb Taper Length Drill Bit, Drill Bit Size 49/64", Drill Bit Point Angle 125, 4 Facet Point Video

#932993-5 | Pkg Qty: 1

$205.02 pkg | $205.02 ea

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Brand
CJT KOOLCARB
Grade
High Performance
Cutting Direction
Right
Item
Taper Length Drill Bit
Decimal Equivalent
0.7656
Maximum Drilling Depth
7-7/8 in.
Depth x Diameter Ratio
2 in.
Mfr. Part Number
17007656
Dimension Type
Fractional Inch
Number of Flutes
2
Drill Bit Dimension Type
Fractional Inch
Number of Pieces
1
Drill Bit Material
Carbide-Tipped
Overall Length
9-7/8 in.
Drill Bit Point Angle
125 deg.
Package Quantity
1
Drill Bit Size
49/64 in.
Point Angle
125 deg.
Drill Point Length
5.06 mm
Point Type
4 Facet, Web Thinned
Finish
Uncoated
Shank Length
2 in.
Flute Length
7-7/8 in.
Shipping Weight
.73 lb.
Flute Type
Straight
Spiral Direction
Right Hand
General
Application
For deeper drilling in. aluminum, copper, cast iron, med-high carbon steels, SS types 303 440F, titanium, fiberglass, hard plastics, graphite and carbon.
Material - Machining
Carbide Tipped
Coolant Fed
Coolant Through
Material Grade - Machining
High Performance
Depth:Dia. Ratio
9xD
Measurement System
Fractional Inch
Drill Bit Grouping
Individual
Primary Material Application ISO Code
H, K, N, P
Drill Bit Point Type
4 Facet Point
Shank Dia.
49/64 in
Drill Diameter Tolerance
+0.0000 in /-0.0010 in
Shank Type - Machining
Straight
Drill Length Class
Taper Length
Web Thinning
Web Thinning
Finish - Machining
Bright (Uncoated)

Product Description

These straight-flute drill bits have a bright finish that is unaffected when the bits' cutting edges are resharpened. Carbide-tipped drill bits have carbide cutting edges that provide excellent hardness, wear resistance, and heat resistance. The bits' body is made from a material that absorb more vibration and shock than carbide, so they are less rigid and less likely to break than solid carbide drill bits. These bits are used in machine setups.These drill bits have holes that allow coolant to flow to their tip to reduce heat and help clear chips during drilling.
