TPI CORP.

Tpi Corp. Electric Wall & Ceiling Unit Heater, 3kW/4kW, 208/240V AC, 1-phase, Air Temp. Rise 53°F

Hover over image to magnify
Electric Utility Heater,Btuh
PI_Asset_1756919
PI_Asset_1763067
PI_Asset_1770781
PI_Asset_1772855
PI_Asset_1774386
PI_Asset_1774387
PI_Asset_1774388
Electric Utility Heater,Btuh
PI_Asset_1756919
PI_Asset_1763067
PI_Asset_1770781
PI_Asset_1772855
PI_Asset_1774386
PI_Asset_1774387
PI_Asset_1774388

#932073-1 | Pkg Qty: 1

$345.57 pkg | $345.57 ea

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Air Flow
238 CFM
Item
Electric Wall and Ceiling Unit Heater
Amperage
14.4 A/16.6 A
Mfr. Part Number
HF5840TC
Brand
TPI CORP.
Mfr. Warranty Length
1 yr.
Frequency
60 Hz
Mounting Location
Wall
Heating Capacity
13652 BtuH
Overall Height
11 in.
Heating Method
Fan Forced
Package Quantity
1
Housing Color
Beige
Phase
1
Housing Finish
Painted
Shipping Weight
16.7 lb.
Housing Material
Steel
Voltage
208/240 VAC
General
Air Temp. Rise
53 Degrees F
Standards
ETL Listed for US and Canada
Contactor Coil Voltage
208/240V AC
Vertical Floor Coverage
12 ft
Horizontal Air Throw
10 ft
Vertical Mounting H
7 to 12 ft
Includes
Ceiling Bracket, Wall
Voltage, Phase
208/240V AC, 1-phase
Nominal Voltage - HVAC
208V AC, 240V AC
Wattage Output
3 kW, 4 kW
Overall Dimensions - H x W x D
11 in x 10-5/8 in x 9-5/8 in

Product Description

Operates On 240 or 208V, 1-Phase, Can Operate As Portable Heater for Bench or Floor Operation, or Mount to The Wall or Ceiling with The Supplied Steel Bracket, Steel Housing with Beige Powder-Coated Finish, Includes Handle with Electric Cord Reel, Fan-Forced Steel Tubular Heating Element Design Generating As Much As 15,086 Btu, Includes 6 ft. Cord with Grounded Plug, Built-In Thermostat, with Automatic Thermal Limit Cut-Out Safety Device, Power-On Indicator and Overheat Pilot Lights, NEMA Plug Configuration (#6-20P)

Item Barcode
9320731
