SQUARE D
Square D Magnetic Motor Starter, 120V AC Coil Volts, NEMA Size: 1, Starter Type: NEMA
Hover over image to magnify
#931964-9 | Pkg Qty: 1
$1,642.06 pkg | $1,642.06 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Accessory Group
D3
Hz
50/60
Action
Reversing
Item
Magnetic Motor Starter
Amps AC
27 A
Mfr. Part Number
8736SCO8V02S
Brand
SQUARE D
NEMA Enclosure Type
Open
Coil Volts
120 VAC
Number of Poles
3
Depth
5.31 in.
Pack Quantity
1
Enclosure NEMA Rating
No Enclosure
Shipping Weight
9.9 lb.
Enclosure Type
Open
Starter Type
NE mA
HP @ 3 Phase - 240 V
7-1/2 hp
Type
NEMA
HP @ 3 Phase - 480 V
10 hp
Width
7.13 in.
Height
6.91 in.
General
HP @ 3 Phase - 208V
7 1/2 hp
HP @ 3 Phase - 575V
10 hp
HP @ 3 Phase - 230V
7-1/2
HP @ 3 Phase 240V
7-1/2
HP @ 3 Phase - 240V
7 1/2 hp
HP @ 3 Phase 480V
10
HP @ 3 Phase - 460V
10
NEMA Size
1
HP @ 3 Phase - 480V
10 hp
Thermal Unit Code
D3
Product Description
NEMA Magnetic Motor Starters with Standard Overload Relays
- Melting alloy thermal overload relays Class 20 thermal protection 2- or 3-pole, 60/50 Hz, 600VAC max. Thermal units sold separately. Full-voltage starters start and stop 1- and 3-phase AC motors. Manual push-to-test and visible trip indicator. Trip-free construction allows overload relay to trip even if reset lever is blocked or in the reset position. Normally open holding circuit contact for 3-wire control. Angled contacts provide high contact pressure and positive seating. Spring-assisted gravity dropout on de-energizing contacts quickly extinguishes any arcing. UL Listed and CSA Certified.
Expertly Selected Product Pairings
Documents
Item Barcode
Magnetic Motor Starter,Nema,
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 1H557 | Magnetic Motor |
 | UNSPSC CODES | 39121521 | |
 | VMRS (ATA) CODES | 053-006-009 | Magnetic Motor |
