LUMAPRO

LumaPro 25 ft. Extension Cord Reel; 125 VAC; Yellow Reel Color

Hover over image to magnify
Retractable Cord Reel,Flying
PI_Asset_1356259
Retractable Cord Reel,Flying
PI_Asset_1356259
Double tap image to magnify
Retractable Cord Reel,Flying
436H02_1
Retractable Cord Reel,Flying
436H02_1

#928506-7Pkg Qty: 1

$93.31 pkg | $93.31 ea

In Stock

Shipping to 43085
Expected to arrive Mon. Mar 31.
|

Technical Specifications

Key Specifications
Brand
LUMAPRO
NEC Cord Designation
SJTOW
Cord Color
Black
Number of Conductors
3
Cord Ending NEMA Configuration
Flying Lead
Number of Outlets
0
Cord Included
Yes
Overall Depth
4 in.
Cord Length
25 ft.
Overall Height
11-1/2 in.
Enclosed Reel
Yes
Overall Width
9-1/2 in.
Enclosure Rating
Not Rated
Package Quantity
1
Feeder Cord Ending
Grounding Plug
Reel Color
Yellow
Feeder Cord Ending NEMA Configuration
5-15P
Reel Material
Steel
Feeder Cord Length
2 ft.
Reel Mounting
Ceiling, Wall
Holds
25 ft. of 14/3
Shipping Weight
7.62 lb.
Indoor/Outdoor
Indoor
Temperature Range
-40 deg. F to 221 deg. F
Item
Extension Cord Reel
Voltage
125 VAC
Maximum Amps
10
Wire Size
16 AWG
Mfr. Part Number
436H02
General
Feeder Cord Ending Configuration
NEMA 5-15P
Max. Amps - Ext. Cords and Outlet Strips
10.0
Gauge/Conductor - Ext. Cords and Outlet Strips
16/3
Standards
cULus
Grade - Ext. Cords and Outlet Strips
General Purpose
Tension Method
Ratchet Lock
Includes
Wall/Ceiling Mounting Bracket
Voltage - Ext. Cords and Outlet Strips
125VAC
Includes Cord
Yes
Winding Method
Spring Retraction

Product Description

Self-retracting cord reels have a spring mechanism that automatically winds the cord back on the reel, making them easier to use than hand-winding cord reels. A stop, or ratchet, holds the cord at the desired length after it's pulled out for use. A quick tug on the cord disengages the stop, causing the spring to fully retract the cord. These reels provide access and storage of extension cords while protecting the cord from wear, tangling, and kinking.

Standard cord reels are spools that hold extension cords to provide access and storage while protecting them from tangling, kinking, and other damage. The cord can be extended to exactly the length needed to power equipment located at a distance from a power source. Self-retracting and motor-driven cord reels automatically wind extended cord back on the reel, while hand-winding cord reels have a handle or knob for winding the cord manually. These cords can be mounted out of the way in a central location, such as on a wall or ceiling, to keep a workspace organized and help reduce tripping hazards. They are commonly used in retail, commercial, and manufacturing applications, including pressure washing, landscaping and ground maintenance, and service garages.
