DSR PROSERIES

DSR Proseries Automatic, Wheeled Battery Charger; Boosting, Charging, Maintaining; For Battery Voltage: 6 V DC, 12 V DC

Hover over image to magnify
Battery Charger,Wheeled,6/12V
PI_Asset_1758582
PI_Asset_1758583
PI_Asset_1770468
PI_Asset_1772559
PI_Asset_1773813
Battery Charger,Wheeled,6/12V
PI_Asset_1758582
PI_Asset_1758583
PI_Asset_1770468
PI_Asset_1772559
PI_Asset_1773813
Double tap image to magnify
Battery Charger,Wheeled,6/12V
485C79_1
485C79_2
485C79_3
485C79_4
485C79_5
Battery Charger,Wheeled,6/12V
485C79_1
485C79_2
485C79_3
485C79_4
485C79_5

#927825-8Pkg Qty: 1

$316.30 pkg | $316.30 ea

In Stock

Shipping to 43085
Expected to arrive Tue. Mar 25.
|

Technical Specifications

Key Specifications
AC Cord Length
6 ft.
Indoor/Outdoor
Indoor/Outdoor
Automatic/Manual
Automatic
Input Voltage
120 VAC
Boost Amps @ Voltage
50A @ 12V
Item
Battery Charger
Brand
DSR PROSERIES
Maintaining Amps @ Voltage
0.14A @ 13.2V
CEC Compliant
CEC Compliant
Material
Plastic
Cable Gauge
6 AWG
Mfr. Part Number
DSR131
Cable Length
2 ft.
Overall Depth
11-7/8 in.
Charge Type
Float
Overall Height
24 in.
Charger Function
Boosting, Charging, Maintaining
Overall Width
16 in.
Charger Style
Wheeled
Package Quantity
1
Charging Amps @ Voltage
125A @ 6V, 250A @ 12V
Portable
Yes
Cranking Amps
100A
Power Cord Length
6 ft.
For Battery Voltage
6 V DC, 12 V DC
Shipping Weight
36 lb.
For Use with Battery Type
AGM, Deep Cycle, Gel
Test Feature
No
Housing Material
Plastic
Timer
No
General
Boost Current @ Voltage
50 A @ 12V, 50 A @ 6V
Includes
(4) Cable Clamp Cleats
Cold Cranking Current @ Voltage
100 A @ 12V
Indoor / Outdoor
Indoor / Outdoor
Green Certification or Other Recognition
California Energy Commission (CEC) Certified
Standards
cUL, UL

Product Description

Battery Charger, Charger Style Wheeled, For Battery Voltage 6, 12, For Use With Battery Type AGM, Deep Cycle, Gel, Charger Function Boosting, Charging, Maintaining, Automatic, Charge Type Auto On/Off, Boost Amps @ Voltage 50A @ 12V, Cold Cranking Amps @ Voltage 100A @ 12V, Charging Amps @ Voltage 250A @ 12V, 125A @ 6V, Maintaining Amps @ Voltage 0.14A @ 13.2V, AC Cord Length 6 ft, Input Voltage 120V AC, Input Amps 11, Overall Width 16 in, Overall Height 24 in, Overall Depth 11 7/8 in

Item Barcode

9278258
Battery Charger,Wheeled,6/12V
