FLEXITALLIC
316SS and Flexible Graphite Spiral Wound Metal Gasket, 7-1/8" Outside Dia., Green Band, Gray Stripe
Hover over image to magnify
#926374 | Pkg Qty: 1
$39.27 pkg | $39.27 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Brand
FLEXITALLIC
Outside Diameter
7-1/8 in.
Inside Diameter
4-3/16 in.
Package Quantity
1
Item
Spiral Wound Metal Gasket
Pipe Size
4 in.
Material
316SS and Flexible Graphite
Shipping Weight
.8 lb.
Metal Detectable
Yes
Temperature Range (Deg. F)
-320 to 842 deg. F
Mfr. Part Number
CGI
Thickness
11/64 in.
General
Continuous Max. Temp. (F)
842 Degrees F
Standards
ASME B16.20,ASME/ANSI Pressure Class-300 LB
Flange Class
Class 300
Winding
316SS with Flexible Graphite
Includes
Inner Ring
Product Description
Spiral Wound Metal Gasket, ANSI class 300 lb flange, 4 in Pipe Size, 7 1/8 in Outside Dia., 4 3/16 in Inside Dia., Metal Detectable Yes, Material of Construction 316SS and Flexible Graphite, 11/64 in Thickness, -320 to 842 Temp. Range (F), Color Gray Stripe, Green Band, Includes Inner Ring, Standards ASME B16.20,ASME/ANSI Pressure Class-300 LB
Item Barcode
Spiral Wound Metal Gasket,4 In,
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 38R313 | Spiral Wound Metal Gasket, |
 | UNSPSC CODES | 31181503 | |
 | VMRS (ATA) CODES | 053-006-009 | Spiral Wound Metal Gasket, |
