JET HVBS-8-DMW Horizontal/Vertical Combo, Stationary Band Saw; 103 in. Blade Length, 3 Speeds

Hover over image to magnify
Mitering Band Saw,9.0/4.5 Amps
PI_Asset_948693
PI_Asset_948694
PI_Asset_948695
PI_Asset_948696
PI_Asset_948697
PI_Asset_948698
PI_Asset_948699
PI_Asset_948700
Mitering Band Saw,9.0/4.5 Amps
PI_Asset_948693
PI_Asset_948694
PI_Asset_948695
PI_Asset_948696
PI_Asset_948697
PI_Asset_948698
PI_Asset_948699
PI_Asset_948700
JET HVBS-8-DMW Horizontal/Vertical Combo, Stationary Band Saw; 103 in. Blade Length, 3 Speeds Video

#925461-1 | Pkg Qty: 1

$4,866.92 pkg | $4,866.92 ea
This item requires special shipping, additional charges may apply.

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Blade Length
103 in.
Operation
Semi-Automatic
Blade Thickness
0.032 in.
Orientation
Horizontal/Vertical Combo
Brand
JET
Overall Depth
24 in.
Current Rating
9.0/4.5 A
Overall Height
43-51/64 in.
Horsepower
0.75 HP
Overall Width
54-45/64 in.
Hz
60 Hz
Package Quantity
1
Item
Stationary Band Saw
Phase
1
Material Application
Metal
Shipping Weight
500 lb.
Mfr. Part Number
HVBS-8-DMW
Voltage
115V AC
Number of Speed Settings
3
General
Blade Wheels Dia.
8.8125 in.
Rectangular Cutting Capacity - Horizontal
7 in. x 8 in.
Cutting Capacity Square
8 in.
Round Cutting Capacity - Horizontal
8 in.
Includes
Vertical Cutting Platform, Wheels, Work Stop Assembly
SFPM Range
64 to 247
Max. Blade Width
1/32 in.
Throat Depth - Vertical
12 in.
Miter Angle Range
45 Degrees Left to 45 Degrees Right

Product Description

Semi-automatic combination vertical and horizontal band saws are manually operated in the vertical position and semi-automatic in the horizontal position. Manually operated band saws have a table that supports the workpiece while the operator pushes it through the blade. Semi-automatic horizontal band saws have a table the operator manually clamps the workpiece to. The saw is programmed to lower the cutting head to complete the cut. Semi-automatic saws lower operator fatigue on medium and large production runs when repeated cuts are made.
