Compx National Keyed Alike Drawer Dead Bolt, For Door Thickness (In.): 7/8, Satin Brass

Hover over image to magnify
Drawer Dead Bolt, Key 915,
Drawer Dead Bolt, Key 915,

#925156-8 | Pkg Qty: 1

$38.15 pkg | $38.15 ea

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Body Thickness
1-3/8 in.
Lock Type
Dead Bolt
Brand
COMPX NATIONAL
Maximum Latching Distance
1/4 in.
Cylinder
57/64 in.
Mfr. Part Number
C8178-915-4
Cylinder Diameter
57/64 in.
Mounting Hardware
Included
Finish
Satin Brass
Mounting Hardware Required
Yes
For Material Thickness
7/8 in.
Mounting Style
Through Hole
Item
Removable Core Plug Cabinet and Drawer Dead Bolt Locks
Number of Keys
2
Key Number
915
Number of Pins
4
Key Type
Alike
Opens With
Key
Lock Mounting Style
Rim
Package Quantity
1
Lock Style
Drawer
Shipping Weight
.5 lb.
General
Cabinet Lock Type
Removable Core Plug Cabinet and Drawer Dead Bolt Locks
Lock Body Shape
Rectangular
Distance Between Mounting Holes
15/16 in
Lock Orientation
Horizontal Left
Drawer and Cabinet Lock Mounting Style
Rim
Mounting Hole Dia.
57/64 in
For Material
Wood
Rear Projection
3/4 in
Includes
Strike
Removable Plug
Yes
Includes Mounting Hardware
Yes
Standards
ANSI/BHMA Grade 2
Latch Bolt Projection
3/4 in
Throw Length
3/4 in
Latch Bolt Shape
Rectangle
Unlock Turn Direction
Clockwise
Lock Body Dimensions
1 15/64 in x 1 5/8 in x 1 3/8 in
Unlocking Radius
Half-turn
Lock Body Finish
Chrome-Plated
Unlocking Radius (Deg.)
360
Lock Body Material
Steel

Product Description

Removable core plug cabinet and drawer dead bolt locks can be rekeyed without removing the whole lock to save time and costs. A required change tool removes and replaces the core plug while keeping the lock body in place. These plugs fit Timberline cylinder bodies. The dead bolt is stronger and more secure than deadlatches. These locks secure cabinets and drawers to prevent theft and unauthorized use of the contents. Removable core plugs are sold separately.
