Schneider Electric 24VAC Coil Volts, General Purpose Relay, 15A @ 277VAC/15A @ 28VDC Contact Rating, Square

Hover over image to magnify
Plug In Relay,8 Pins,Square,
Plug In Relay,8 Pins,Square,
Schneider Electric 24VAC Coil Volts, General Purpose Relay, 15A @ 277VAC/15A @ 28VDC Contact Rating, Square Video

#924661-9 | Pkg Qty: 1

$19.13 pkg | $19.13 ea

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
AC Contact Rating
15 A @ 277 V
Mounting
Plug In
Base Type
Square
Number of Contacts
2
Body Depth
1.1 in.
Number of Pins
8
Body Height
1.54 in.
Number of Poles
2
Body Width
0.83 in.
Overall Height
1.78 in.
Brand
SCHNEIDER ELECTRIC
Package Quantity
1
Coil VA Rating
1.2
Pins
8
Coil Volts
24 VAC
Plug-In Relay Style
General Purpose
Contact Form
DPDT
Push To Test
Lockable
Contact Material
Silver Alloy
Relay Power Consumption
1.2 VA
Contact Rating
15 A @ 277 VAC/28 VDC
Resistive Contact Amp Rating
15
DC Contact Rating
15 A @ 28 V
Response Time
20 msec
HP @ 240 V
1
Shipping Weight
.09 lb.
Hz
50/60
Socket
Mfr. No. 70-459-1, 70-782D8-1A
Input Power Consumption
1.2 VA
Socket Code
D
Item
General Purpose Relay
Status Indicator
LED and Mechanical Flag
Mfr. Part Number
782XBXM4L-24A
Type
Plug-In
General
AC Contact Rating - Relay
15A @ 277V
HP @ 120V
1/2 hp
Base Type - Plug In Relay
Square
HP @ 240V
1 hp
Body Depth - Relay
1.1 in
Mounting - Relay
Plug In
Body Height - Relay
1.54 in
Number of Pins - Relay
8
Body Width - Relay
0.83 in
Overall Height - Relay
1.78 in
Contact Form - Relay
DPDT
Power Consumption - Relay
1.2 VA
DC Contact Rating - Relay
15A @ 28V
Socket Code - Relay
D
Features
Removable ID Tag
Standards
CSA Certified, CE Marked

Product Description

General Purpose Relay, Coil Volts 24V AC, AC Contact Rating - Relay 15A @ 277V, DC Contact Rating - Relay 15A @ 28V, Base Type - Plug In Relay Square, Number of Pins - Relay 8, Contact Form - Relay DPDT, Mounting - Relay Plug In, Socket Code - Relay D, Power Consumption - Relay 1.2 VA, Contact Material Silver Alloy, Status Indicator LED and Mechanical Flag, Push To Test Lockable
