FLEXITALLIC
316SS and Flexible Graphite Spiral Wound Metal Gasket, 2-1/8" Outside Dia., Green Band, Gray Stripe
Hover over image to magnify
#924231-3 | Pkg Qty: 1
$5.66 pkg | $5.66 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Brand
FLEXITALLIC
Outside Diameter
2-1/8 in.
Inside Diameter
3/4 in.
Package Quantity
1
Item
Spiral Wound Metal Gasket
Pipe Size
1/2 in.
Material
316SS and Flexible Graphite
Shipping Weight
.01 lb.
Metal Detectable
Yes
Temperature Range (Deg. F)
-320 to 842 deg. F
Mfr. Part Number
CG
Thickness
11/64 in.
General
Continuous Max. Temp. (F)
842 Degrees F
Standards
ASME B16.20,ASME/ANSI Pressure Class-300-400-600 LB
Flange Class
Class 300, Class 400, Class 600
Winding
316SS with Flexible Graphite
Product Description
Metal-Reinforced Spiral-Wound Ring Gaskets
- Meet ANSI B16.20.
- Flexitallic CG
- temperature range: -150° to 842°F
- 316 stainless steel windings with flexible graphite filler. Feature an external ring that centers the gasket on the flange face. Provides additional radial strength to help prevent gasket blowout and acts as a compression stop. General purpose gasket suitable for use with raised face and flat face flanges.
Item Barcode
Spiral Wound Metal Gasket,1/2
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 38R328 | Spiral Wound Metal Gasket, |
 | UNSPSC CODES | 31181503 | |
 | VMRS (ATA) CODES | 053-006-009 | Spiral Wound Metal Gasket, |
