HARRINGTON

Harrington H4 Electric Chain Hoist, 2000 lb. Load Capacity, 115/230V, 15 ft. Hoist Lift, 7 fpm

Hover over image to magnify
Elec. Chain Hoist w/Trolley,
Elec. Chain Hoist w/Trolley,

#922835-4 | Pkg Qty: 1

$3,471.46 pkg | $3,471.46 ea
This item requires special shipping, additional charges may apply.

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Amps @ Low Volts
16.9
Load Capacity
2000 lb.
Brake
Pull-Rotor
Lubrication Type
Oil Bath
Brand
HARRINGTON
Material
Die Cast Aluminum
Classification
H4
Mfr. Part Number
SNERP010L-15
Clutch Style
Friction Clutch
Mfr. Warranty Length
1 yr.
Control
110v
Minimum Between Hooks
16-1/2 in.
Finish
Electrostatic Enamel
Motor HP
0.6
Hoist Lift
15 ft.
Package Quantity
1
Hoist Mount
Push Trolley
Phase
1
Housing Depth
7-1/2 in.
Reeving
1
Housing Length
23-1/4 in.
Shipping Weight
137 lb.
Housing Width
13-13/16 in.
Thermal Protection
Option
Item
Electric Chain Hoist
Voltage
115/230
Lift Speed
7 fpm
General
Beam Height
4-5/8"
Headroom
16-1/2"
Clutch
Friction Clutch
Includes
Chain Container,, Push Trolley
Control Cord
11 ft
Min. Between Hooks
16 1/2 in
Fits Beam Flange W
2-1/4 in to 5 in
Standards
ANSI/ASME B30.16, ASME HST-1M,

Product Description

Electric Chain Hoists

  • H4 Rated Die-cast aluminum Friction clutch Oil bath lubrication Include chain container
  • SNERP Electric Chain Hoists with Push Trolley
  • Pull-rotor brake Meet ANSI/ASME B30.16, ASME HST-1M
  • Feature hinged control panel, sealed housing, and durable load sheave. Compact design. Push trolley provides mobility.
