OSG
Square End Mill, 5/16" Milling Diameter, Number of Flutes: 4, 1-3/8" Length of Cut
Hover over image to magnify
#922722-9 | Pkg Qty: 1
$33.13 pkg | $33.13 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Brand
OSG
Item
Square End Mill
Cast Iron Compatibility
Yes
Length of Cut
1-3/8 in.
Cutting Direction
Right
List Number
545
Cutting Direction
Right Hand
Mfr. Part Number
5450400
Cutting Type
Non Center
Milling Diameter
5/16 in.
Dimension Type
Fractional Inch
Non Ferrous Compatability
No
End Mill Application
Finishing
Number of Flutes
4
End Mill Cutting Type
Non-Center Cutting
Overall Length
3-1/8 in.
End Mill Material
High Speed Steel
Pack Quantity
1
Finish
Bright (Uncoated)
Primary Material Application
Steel
Grade
General Purpose
Shank Diameter
3/8 in.
Hardened Compatibility
Yes
Shipping Weight
.1 lb.
Helix Angle
30 deg.
Single End/Double End
Single End
General
Drilling Tool Configuration
Individual
Measurement System
Fractional Inch
End Mill Style
Square
Milling Dia.
5/16 in
Finish - Machining
Bright (Uncoated)
Primary Material Application ISO Code
P
Material - Machining
Cobalt
Shank Dia.
3/8 in
Material Grade - Machining
General Purpose
Shank Type - Machining
Weldon Flat
Product Description
Four-flute end mills clear chips more quickly than end mills with more flutes and allow for higher feed rates than end mills with fewer flutes. They also typically have larger cores and are less prone to breaking than end mills with fewer flutes. The bright finish on these end mills provides a smooth, polished surface.
Item Barcode
End Mill, 5/16" Dia, 1-3/8"
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 35DK39 | End Mill, 5/ 16" Dia, 1-3/ |
 | UNSPSC CODES | 27112803 | |
 | VMRS (ATA) CODES | 053-006-009 | End Mill, 5/ 16" Dia, 1-3/ |
