DAYTON
Dayton 24" Whole House Fan Premium Ceiling Shutter / Ceiling Shutter, 24" x 24" Opening Required
Hover over image to magnify
#921447-1 | Pkg Qty: 1
$166.66 pkg | $166.66 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Brand
DAYTON
Number of Panels
1
Item
Whole House Fan Premium Ceiling Shutter / Ceiling Shutter
Package Quantity
1
Material
Extruded Aluminum Frame and G-90 Galvanized Tie Rods
Product Size
26 in. x 26 in.
Mfr. Part Number
4C224
Shipping Weight
7.65 lb.
Mounting Position
Horizontal
General
Fits Fan Dia.
24 in
Shutter Free Area
3.112 sq ft
For Use With
24 in. Whole House Fans
Shutter Mounting Location
Ceiling
Frame Depth
1 3/8 in
Shutter Mounting Position
Horizontal
Max. Velocity
2250 FPM
Shutter Opening Required
24 in x 24 in
Mounting Hole Size
Prepunched
Shutter Overall Size
26 in x 26 in
Shutter Construction Material
Extruded Aluminum Frame and G-90 Galvanized Tie Rods
Product Description
These ceiling shutters fit flush in ceiling opening below whole-house fans. They feature tie rods at each side to assure a uniform opening when the fan is operating. Also has white louvers with felted edges; louvers are reinforced with galvanized steel.
Expertly Selected Product Pairings
Documents
Item Barcode
Fan Shutter,24 In,White
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 4C224 | Fan Shutter, 24 In,White |
 | UNSPSC CODES | 40101504 | |
 | VMRS (ATA) CODES | 053-006-009 | Fan Shutter, 24 In,White |
