ZOELLER

4/10 HP Automatic Submersible Sewage Pump, 115 Voltage, 22 GPM of Water @ 15 Ft. of Head

Hover over image to magnify
Submersible Sewage Pump,4/10HP,
PI_Asset_1766915
Submersible Sewage Pump,4/10HP,
PI_Asset_1766915

#920583-9 | Pkg Qty: 1

$688.10 pkg | $688.10 ea

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Agency Compliance
CSA Certified, UL Listed
Maximum Temperature (Deg. F)
130
Amps
9.4
Mfr. Part Number
M264
Base Material
Polypropylene
Mfr. Warranty Length
3 yr.
Bearing Type
Sleeve
Motor RPM
1725
Body Material
Cast Iron
Motor Type
Hermetically-Sealed, Oil-Filled, Permanent Split Capacitor
Brand
ZOELLER
Off Point
4-1/2 in.
Cord Length
10 ft.
On Point
12-1/2 in.
Diameter
11-23/64 in.
Overall Height
14-3/4 in.
Discharge
2 in. FNPT
Package Quantity
1
Discharge NPT
2 in.
Phase
1
Duty Cycle
Continuous
Pump Body Material
Cast Iron
GPM of Water @ 10 Ft. of Head
60
Pump HP
4/10
GPM of Water @ 15 Ft. of Head
22
Pump Type
Automatic
GPM of Water @ 5 Ft. of Head
90
RPM
1725 RPM
Height
14-3/4 in.
Shaft Material
Carbon/Ceramic
Horsepower
4/10
Shaft Seal
Carbon/Ceramic
Housing
Cast Iron
Shaft Seal Material
Carbon, Ceramic
Housing Material
Cast Iron
Shipping Weight
34.2 lb.
Impeller Material
Thermoplastic
Switch Type
Vertical
Input Phase AC
1
Thermal Protection
Yes
Item
Submersible Sewage Pump
Top Material
Cast Iron
Maximum Diameter Solids
2 in.
Type
Automatic
Maximum Head
18 ft.
Voltage
120 VAC
Maximum Liquid Temperature
130°F
Warranty
1 yr.
General
Body Dia.
11 23/64 in
Nominal Voltage
110V AC
Discharge Dia.
2 in
Phase - Pumps
1
Discharge Gender
Female
Rated Voltage
115V AC
Discharge Standard
NPT
Shaft Seal Material - Pumps
Carbon, Ceramic
Flow Rate @ 10 Ft. of Head
60 gpm
Standards
CSA Certified
Flow Rate @ 15 Ft. of Head
23 gpm
Switch Actuation
Vertical Float
Min. Sump Pit Dia.
18 in
Switch Electrical Connection
Integral

Product Description

These general purpose 110 to 120V sewage ejector pumps remove sewage containing solids from drains where a gravity system won't work, such as in septic systems that are below the main sewer line. They are compatible with most standard U.S. residential electrical wall outlets.
