3/8" General Purpose Air Regulator , 70 cfm Max. Flow - Regulators

Name: 3/8" General Purpose Air Regulator , 70 cfm Max. Flow - Regulators
Brand: SPEEDAIRE
SKU: 9182608
Price: 55.38 USD
Availability: InStock

Hover over image to magnify

Double tap image to magnify

#918260-8Pkg Qty: 1

$55.38 pkg | $55.38 ea

In Stock

Shipping to 43085

Expected to arrive Fri. Apr 04.

Technical Specifications

Key Specifications

Adjustment

30 psi

Mfr. Part Number

1WH33

Air Consumption

scfm

NPT

3/8 in.

Body Material

Zinc

Overall Height

4.07 in.

Brand

SPEEDAIRE

Overall Width

1.97 in.

Item

General Purpose Air Regulator

Package Quantity

Maximum Flow

70 cfm

Pipe Size

3/8 in.

Maximum Inlet Pressure

300 psi

Shipping Weight

.95 lb.

Maximum Pressure

300 psi

Type

Preset

Maximum Temperature

150 deg. F

Valve Design

Balanced

General

Adjustment Range

30 psi

Max. Flow - Regulators

70 cfm

Adjustment Range - Regulators

Non-Adjustable, 30 psi

Max. Inlet Pressure - Regulators

300 psi

Air Inlet Gender

Female

Overall Height - Regulators

4.07 in

Air Inlet Type

NPT

Overall Width - Regulators

1.97 in

Air Outlet Gender

Female

Pipe Size - Regulators

3/8 in

Air Outlet Size

3/8 in

Pressure Gauge Port Size

1/8 in

Air Outlet Type

NPT

Pressure Gauge Port Type

NPT

Compressed Air Regulator Product Grouping

General Purpose Air Regulator

Regulator Body Material

Aluminum or Zinc

Gauge Port

1/8 in NPT

Product Description

Features a modular connector that allows easy removal and swap out, plus 2 full-flow gauge ports. Manifold regulator provides multiple pressures from a common inlet. For Max. Flow, the CFM flow is measured with 150 psig inlet adjusted to set pressure of 90 psig (while increasing flow) and a 15 psig drop.
