3M 9-1/2" Insulated Crimper, 26 to 6AWG Capacity

Name: 3M 9-1/2" Insulated Crimper, 26 to 6AWG Capacity
Brand: 3M
SKU: 9181924
Price: 92.28 USD
Availability: InStock

Hover over image to magnify

#918192-4 | Pkg Qty: 1

$92.28 pkg | $92.28 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications

Adjustable

Manual

Maximum Cable Diameter

6 ga

Brand

Maximum Stripping Capacity- Solid Wire

6 AWG

Capacity

26 to 6 AWG

Maximum Stripping Capacity- Standard Wire

6 AWG

Characteristics

High-strength Heat Treated Carbon Steel Provides Dependable Service and Long Life, Cushioned Insulated Handles for Comfortable Grip

Mfr. Part Number

TH-450

Crimping Tool

Crimper

Minimum Stripping Capacity- Solid Wire

22 AWG

Cuts

Yes

Minimum Stripping Capacity- Standard Wire

22 AWG

Function

Strips and Cuts 26- to 6-ga. Wire; Cuts 10-32, 10-24, 8-32, 6-32, and 4-40 Bolts

Overall Length

9-1/2 in.

Handle Style

Standard

Package Quantity

Handle Type

Cushion Grip

Sets or Singles

Single

Insulated / Uninsulated

Insulated

Shipping Weight

.6 lb.

Item

Crimper

Strips

Yes

General

Adjustment Mechanism

Manual

Maximum Stripping Capacity - Stranded Wire

6 AWG

Application

For Broad Range of Insulated and Non-insulated Terminals and Connectors

Maximum Wire/Cable Diameter

6 ga

Connectors Crimped

Insulated Connectors, Noninsulated Connectors, Terminals

Minimum Stripping Capacity - Solid Wire

22 AWG

Cutting Capacities

26 to 6 AWG

Minimum Stripping Capacity - Stranded Wire

22 AWG

Features

High-strength Heat Treated Carbon Steel Provides Dependable Service and Long Life, Cushioned Insulated Handles for Comfortable Grip

Minimum Wire/Cable Diameter

26 ga

For Use With

For Broad Range of Insulated and Non-insulated Terminals and Connectors

Stripping Capacity - Solid Wire

6 AWG, 8 AWG, 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG

For Wire/Cable Type

Solid Wire, Stranded Wire

Stripping Capacity- Cable

0.645 to 4.11 mm

Gauges Crimped

12 to 6 AWG (Noninsulated), 26 to 14 AWG (Noninsulated), 26 to10 AWG (Insulated), 6 to 8 AWG (Insulated)

Stripping Capacity- Stranded Wire

6 AWG, 8 AWG, 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG

Includes

Closed End Connectors, Crimp Sleeves, Flags, Standard Parts

Tool Functions

Cut, Screw Shear

Maximum Stripping Capacity - Solid Wire

6 AWG

Product Description

The 3M™ insulated crimper is a scissors style or anvil-type wire cutter that crimps a broad range of terminals and conductor styles including scrimp sleeves, standard parts, connectors, disconnectors, flags, and both insulated and noninsulated terminals. Versatile crimper has high-strength, heat-treated carbon steel construction for impact resistance. Features crimp dies for closed-end connectors. Includes wire-stripping stations for circumferential, effortless cutting.
