Omron 12VDC Coil Volts, General Purpose Relay, 10A @ 240VAC/10A @ 28VDC Contact Rating, Square
Hover over image to magnify
#917843-5 | Pkg Qty: 1
$9.23 pkg | $9.23 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
AC Contact Rating
10 A @ 240 V
Mfr. Part Number
G2R-1-S-DC12(S)
Auxiliary Contact Configuration
NO/NC
Mounting
Plug In
Base Type
Square
Number of Pins
5
Body Depth
1.14 in.
Number of Poles
1
Body Height
1.4 in.
Overall Height
1.6 in.
Body Width
0.51 in.
Package Quantity
1
Brand
OMRON
Pins
5
Coil VA Rating
0.52
Plug-In Relay Style
General Purpose
Coil Volts
12 VDC
Push To Test
Manual
Contact Amp Rating
7
Relay Power Consumption
0.5 W
Contact Form
SPDT
Resistive Contact Amp Rating
10
Contact Material
Cadmium Free
Response Time
10 msec
Contact Rating
10 A @ 250 VAC/30 VDC
Shipping Weight
.04 lb.
DC Contact Rating
10 A @ 28 V
Socket
Mfr. No. P2RF-05-E
Inductive Contact Amp Rating
7
Socket Code
H
Input Power Consumption
0.5 W
Status Indicator
Mechanical Flag
Item
General Purpose Relay
General
AC Contact Rating - Relay
10A @ 240V
HP @ 120V
1/3 hp
Aux. Contact Configuration
NO/NC
HP @ 240V
1/2 hp
Base Type - Plug In Relay
Square
Mounting - Relay
Plug In
Body Depth - Relay
1.14 in
Number of Pins - Relay
5
Body Height - Relay
1.4 in
Overall Height - Relay
1.6 in
Body Width - Relay
0.51 in
Power Consumption - Relay
0.5 W
Contact Form - Relay
SPDT
Socket Code - Relay
H
DC Contact Rating - Relay
10A @ 28V
Standards
CSA Certified
Product Description
Slim and space-saving power plug in relay with built-in mechanical flag indicator. Provides high switching power and has manual push to test. Designed with cadmium-free contact material and ia suitable for general-duty applications. Includes standard socket-mount or solder terminals and nameplate.
Expertly Selected Product Pairings
Item Barcode
Plug In Relay,5 Pins,Square,
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 4FE17 | Plug In Relay,5 Pins, |
 | UNSPSC CODES | 39122324 | |
 | VMRS (ATA) CODES | 053-006-009 | Plug In Relay,5 Pins, |
