LOCTITE
Loctite Threadlocker: Series 277, Threadlocker, Red, Liquid, 250 mL, Bottle
Hover over image to magnify
#917704 | Pkg Qty: 1
$185.22 pkg | $185.22 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Appearance
Red
Package Quantity
1
Begins to Harden
60 min.
Performance Temperature Range
-65 deg. F to 300 deg. F
Brand
LOCTITE
Physical Form
Liquid
Chemical Type
Anaerobic
Removable With
Heat and Hand Tools
Color Family
Red
Series
277
Fills
Gaps Between Threads
Shipping Weight
.75 lb.
Fixture Time
60 min.
Size
250 mL
Flash Point
200 deg. F
Specific Gravity
1.12
For Fastener Diameter
Up to 7/8 in.
Temperature Range
-65 to 300 deg. F
Full Cure
24 hr.
Threadlocker Classification
Threadlocker
Full Cure Time
1 day
Threadlocker Disassembly
Permanent
Gap Fill
0.01 in.
Threadlocker Strength
High Strength
Item
High-Strength Threadlocker
Type
High Strength Threadlocker
Mfr. Part Number
88449
Viscosity
7,000 cP
Net Weight
250 mL
General
Application
Stronger Than 262, 271 or 272. Locks Fasteners Up to 1-1/2 in. Dia; Removable With Heat and Hand Tools
Pack Size
1 EA
Breakaway Torque
280 in-lb
Prevailing Torque
350 in-lb
Breakaway Torque Range
201 in-lb to 300 in-lb
Product Form
Liquid
Clean Up Method
Solvent, Wire Brush
Recommended Surface Preparation
Dry Surface
Compatible Materials
Bronze, Copper, Iron, Manganese, Nickel, Steel
Removal Method
Hand Tool and Heat
Compatible Primer ( Part Number)
4KL11
Standards
OSHA Hazard Communication, RoHS Compliant
Compatible Primer Series
Loctite 7649
Storage Requirements
8 Degrees to 21 Degrees C
Container Size Range
Over 1.1 oz
Threadlocker Properties
Oil Tolerant
Container Size and Type
8.45 fl oz Bottle
Torque and Strength
280 in-lb High
Container and Size
Bottle Over 1.1 oz
VOC Content Range
10 g/L and Under
Cure Type
Anaerobic
VOC Content Weight Percentage
0.0001
For Material Type
Brass, Bronze, Copper, Iron, Manganese, Monel, Nickel, Steel
Working Time
45 min
For Maximum Thread Diameter
7/8 in
Working Time Range
More Than 10 min
Minimum Viscosity
6,000 cps
Product Description
Specialty Threadlockers
- Fill gaps between threads and securely mate surfaces to form solid, unitized assemblies. Prevent fasteners from loosening due to vibration and protect against rust and corrosion
- Threadlockers
- Fill gaps between threads to help form solid, unitized assemblies. Prevent fasteners from loosening due to vibration and protect against rust and corrosion
- High-Strength
- Fasteners can be removed with hand tools after heat is applied.
- Large Fastener
- Fast-curing; for heavy-duty applications. For fasteners up to 7/8" dia.
Expertly Selected Product Pairings
Compliance & Restrictions
SDS Available View
Item Barcode
Threadlocker 277,250mL Bottle,
