Home All Products Electrical Battery Chargers, Booster Packs & Jumper Cables Battery Chargers SKU: 917524-1

Associated Equipment Automatic, Wheeled Battery Charger and Starter; Boosting, Charging, Maintaining; For Battery Voltage: 12 V DC

Name: Associated Equipment Automatic, Wheeled Battery Charger and Starter; Boosting, Charging, Maintaining; For Battery Voltage: 12 V DC
Brand: ASSOCIATED EQUIPMENT
SKU: 9175241
Price: 1024.94 USD
Availability: InStock

Hover over image to magnify

#917524-1 | Pkg Qty: 1

$1,024.94 pkg | $1,024.94 ea

Drop Ship Item

Shipping to 60045

Technical Specifications

Key Specifications

AC Cord Length

6 ft.

Input Current

45 A

Amps

40A

Input Voltage

120 VAC

Automatic/Manual

Automatic

Item

Battery Charger and Starter

Boost Amps @ Voltage

130 A @ 12 V

Lead Size

4 AWG

Brand

ASSOCIATED EQUIPMENT

Maintaining Amps @ Voltage

45A @ 14.8V

CEC Compliant

Material

Steel

Cable Gauge

4 AWG

Mfr. Part Number

ESS6007B

Cable Length

6 ft.

Overall Depth

17 in.

Charge Time

2 hr.

Overall Height

30 in.

Charge Time 12 V

Variable

Overall Width

16 in.

Charge Time 6 V

1/2 to 2 hr.

Package Quantity

Charge Type

Smart

Peak Amps

130A

Charger Function

Boosting, Charging, Maintaining

Portable

Yes

Charger Style

Wheeled

Power Cord Length

6 ft.

Charging Amps @ Voltage

45 A @ 12 V

Shipping Weight

40.8 lb.

Cranking Amps

130A

Test Feature

Yes

For Battery Voltage

12 V DC

Timer

Microprocessor Controlled

For Use with Battery Type

AGM, Deep Cycle, Gel, Lead Acid

UL Rated Amps 12 V

40A

Housing Material

Steel

Voltage Rating

120 VAC

Indoor/Outdoor

General

Average Charge Time 12 V High

Variable

Green Certification or Other Recognition

California Energy Commission (CEC) Certified

Average Charge Time 12 V Low

Variable

Housing Material

Steel

Average Charge Time 6V High

1/2 to 2 hr.

Includes

Clamp Bar for Clamp Storage, Dead Battery Override Control

Avg. Charge Time 12V High

Variable

Includes Test Feature

Yes

Avg. Charge Time 12V Low

Variable

Indoor / Outdoor

Avg. Charge Time 6V High

1/2 to 2 hr.

Input Current

45 A

Boost Current @ Voltage

130 A @ 12V

Input Voltage

120 VAC

Cable Wire Gauge

4 AWG

Power Cord Length

6 ft.

Charge Time 12V

Variable

Standards

UL, cX - ANALYZER

Charge Time 6V

1/2 to 2 hr.

UL Rated Amps 12V

40A

Cold Cranking Current @ Voltage

130 A @ 12V

UL Rated Amps Start

130A

Product Description

Battery Charger and Starter, Charger Style Wheeled, For Battery Voltage 12, For Use With Battery Type AGM, Deep Cycle, Gel, Lead Acid, Charger Function Boosting, Charging, Maintaining, Automatic, Charge Type Smart, Boost Amps @ Voltage 130A @ 12V, Charging Amps @ Voltage 45A @ 12V, Maintaining Amps @ Voltage 45A @ 12V, AC Cord Length 6 ft, Input Voltage 120V AC, Overall Width 16 in, Overall Height 30 in, Overall Depth 17 in, Cable Gauge 4 AWG, Cable Length 6 ft, Test Feature Yes

Item Barcode

Battery Charger/Starter,40A,
