PHILIPS ADVANCE

Electronic CFL Ballast, 70 Max. Lamp Watts, 120-277 V, Rapid Ballast Start Type

Hover over image to magnify
Cfl Ballast,Electronic,93W,120/
PI_Asset_966993
Cfl Ballast,Electronic,93W,120/
PI_Asset_966993
Electronic CFL Ballast, 70 Max. Lamp Watts, 120-277 V, Rapid Ballast Start Type Video
Electronic CFL Ballast, 70 Max. Lamp Watts, 120-277 V, Rapid Ballast Start Type Video

#915657-8 | Pkg Qty: 1

$51.66 pkg | $51.66 ea

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Ballast Family
SmartMate
Length
4-1/4 in.
Ballast Type
Electronic
Light Output
Normal
Brand
PHILIPS ADVANCE
Mfr. Part Number
ICF-2S42-M2-LD-K
Dimming
No
Number of Lamps
2
Dimming Type
No Dimming
Package Quantity
1
Height
1 in.
Shipping Weight
1.05 lb.
Item
CFL Ballast
Start Type
Rapid
Lamp Type
CFL
Width
2-7/16 in.
Lamp Watts
70 W
General
Ballast Bulb Type
Compact Fluorescent
Number of Bulbs Supported
2
Ballast Factor
0.97
Number of F26DBX Lamps
2
Ballast Start Type
Programmed
Number of F282D Lamps
2
Brand and Series
SmartMate(R)
Number of F282D/4P Lamps
2
Bulb Base Type
4-Pin (GX24q), (PL-T)
Number of F32BX Lamps
2
Dimension Reference
A39
Number of F382D/4P Lamps
2
Dimming Method
No Dimming
Number of F42BX Lamps
2
Dimming Range
No Dimming
Operating Amps @ 120V
0.33 A, 0.78 A
Includes
Lead Wire (Color Coded), Mounting Plate Adapter, Wire Extraction Tool
Power Factor
0.98
Max. Bulb Watts
70 W
Special Features
Dual Connector
Max. Operating Temp.
158 Degrees F
Total Harmonic Distortion
Less Than 10%
Min. Starting Temp.
0 Degrees F
Wiring Type
Series

Product Description

Rapid-start electronic fluorescent ballasts turn on lights near-instantaneously. They are less damaging to light bulbs than instant-start ballasts and are used in lighting fixtures that will be turned on or off frequently via occupancy sensors and other lighting controls that automatically operate the lights. The ballasts provide a small amount of voltage to preheat the bulbs' filaments before the bulbs turn on.
