HARRINGTON
Harrington H4 Electric Chain Hoist, 6000 lb. Load Capacity, 115/230V, 15 ft. Hoist Lift, 3.5 fpm
Hover over image to magnify
#914386-3 | Pkg Qty: 1
$5,707.48 pkg | $5,707.48 ea
This item requires special shipping, additional charges may apply.
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Amps @ Low Volts
23.9
Lift Speed
3.5 fpm
Brake
Pull Rotor Motor
Load Capacity
6000 lb.
Brand
HARRINGTON
Lubrication Type
Oil Bath
Classification
H4
Material
Die Cast Aluminum
Clutch Style
Friction
Mfr. Part Number
SNER030C-15
Color Family
Yellow
Mfr. Warranty Length
1 yr.
Control
110V Push Button Control Pendant
Minimum Between Hooks
29-1/2 in.
Finish
Electrostatic Enamel
Motor HP
1.2
Hoist Lift
15 ft.
Package Quantity
1
Hoist Mount
Hook Mounted - No Trolley
Phase
1
Housing Depth
8-5/16 in.
Reeving
2
Housing Length
29-1/2 in.
Shipping Weight
263 lb.
Housing Width
13-3/16 in.
Thermal Protection
No
Item
Electric Chain Hoist
Voltage
115/230
General
Clutch
Friction
Includes
Chain Container
Control Cord
11 ft
Min. Between Hooks
29 1/2 in
Headroom
29-1/2"
Standards
ASME B30.16, ASME HST-1, NFPA 70
Product Description
Electric Chain Hoists
- H4 Rated Die-cast aluminum Friction clutch Oil bath lubrication Include chain container SNER Electric Chain Hoists
- Pull-rotor motor brake with no brake coil to fail Heat-treated helical and spur gears Meet ASME B30.16, ASME HST-1, and NFPA 70 Designed with heavy-duty motor, heat-treated Grade 80 nickel-plated chain, easy access control panel, and cast-iron chain guide. Single-speed duty cycle is 60 min.
