THOMAS & BETTS
Thomas & Betts C Tap, Blue, Die Code 24, Main 10 to 8 AWG, Branch 10 to 12 AWG, Height 7/16", Length 9/16"
Hover over image to magnify
#912683-2 | Pkg Qty: 1
$6.94 pkg | $6.94 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Brand
THOMAS & BETTS
Length
9/16 in.
Color Code
Blue
Material of Construction
Wrought Copper
Description/Special Features
Ideal for Pigtailing, 2-way Splicing or Tapping to an Unbroken Continuous Main, 600V Applications
Mfr. Part Number
54710
Die Code
24
Package Quantity
1
Height
7/16 in.
Shipping Weight
.01 lb.
Item
C Tap
Wire Range
Main 10 to 8 AWG, Branch 10 to 12 AWG
General
Cable Combo Branch Maximum
10
For Minimum Equal Wire Size
10 AWG (Main), 12 AWG (Branch)
Cable Combo Branch Minimum
12
For Minimum Run Wire Size
10 AWG
Cable Combo Main Maximum
8
For Minimum Tap Wire Size
12 AWG
Cable Combo Main Minimum
10
For Run Wire Size
10 AWG, 8 AWG
Compatible Installation Tool Model Number
13454, 13461, 13475, 13477, 6TON24, TBM6224
For Tap Wire Size
10 AWG, 12 AWG
Compatible Part Number
3LJ70, 3LJ75, 3LJ86, 3LJ88
Run Wire Size Range
10 AWG – 8 AWG
Compatible with Product Type
Crimping Die
Special Features
Ideal for Pigtailing, 2-way Splicing or Tapping to an Unbroken Continuous Main, 600V Applications
For Maximum Equal Wire Size
10 AWG (Branch), 8 AWG (Main)
Standards
UL
For Maximum Run Wire Size
8 AWG
Tap Wire Size Range
12 AWG – 10 AWG
For Maximum Tap Wire Size
10 AWG
Termination Style
Crimp
Product Description
This C Tap features high-conductivity wrought copper construction, with heavy reinforcing ribs to help locate the compression dies and strengthen the compression joint. They also help to ensure positive, all-around compression with low resistance and high pullout values.
Expertly Selected Product Pairings
Documents
Item Barcode
Connector,Compression
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 3LM28 | Connector, Compression |
 | UNSPSC CODES | 39121409 | |
 | VMRS (ATA) CODES | 053-008-004 | Connector, Compression |
