SPAN
Pressure Gauge with Internal Seal: 0 to 600 psi, LFS-210, 2 1/2 in Dial, Buna-N, Brass, Bottom
Hover over image to magnify
#912115-2 | Pkg Qty: 1
$51.96 pkg | $51.96 ea
Drop Ship Item
Shipping to 60045
Technical Specifications
Key Specifications
Bezel Material
Zytel Nylon
Gauge Primary Range Units
psi
Brand
SPAN
Gauge Sensor Material
Copper Alloy
Calibration Certificate Included
No
Gauge Socket Material
Brass
Gauge Accuracy
±1.0%
Hazardous Location Rating
Not Rated
Gauge Application
Fire Apparatus, Hydraulics, Marine, Military, Transportation, Water Treatment Applications
Item
Pressure Gauge with Internal Seal
Gauge Case Color
Black
Liquid Filled
Yes
Gauge Case Material
Zytel Nylon
Mfr. Part Number
LFS-210-600-G-KEMX
Gauge Connection Location
Bottom
Mounting Type
Stem-Mount
Gauge Connection Size
1/4 in.
Operating Temperature Range
-40 deg. F to 150 deg. F
Gauge Connection Type
MNPT
Package Quantity
1
Gauge Filled With
Glycerin
Pressure Range
0 to 6000
Gauge Lens Material
Acrylic
Series
LFS-210
Gauge Nominal Dial Size
2-1/2 in.
Shipping Weight
.86 lb.
Gauge Panel Mountable
No
Vibration Resistance
Liquid-Filled
General
Accuracy Grade
ASME B40.100 Grade 1A
Pressure Range Type
Pressure
Accuracy Scale
Full Scale
Pressure and Vacuum Gauge Type
Pressure Gauge
Bezel Mounting Type
Removable
Primary Pressure Range
0 to 600
Case Construction
Corrosion Resistant; Chemical Resistant; Weather Resistant
Primary Scale Minor Graduations
10
Case Depth
1.41 in
Primary Scale Numeric Increments
100
Case Diameter
3.2 in
Primary Scale Units
psi
Case Finish
Gloss
Process Connection
1/4 in NPT Male
Clog Resistant
Yes
Process Connection Gender
Male
Dial Face Material
Aluminum
Process Connection Location
Bottom
Diaphragm Seal Type
Clamped
Process Connection Size
1/4 in
Field Fillable
Yes
Process Connection Type
NPT
Freeze Resistant Movement
Yes
Removable Bezel
Yes
Gauge Case Liquid
Glycerin
Scale Type
Single
IP/NEMA Rating
IP65, NEMA 4X
Seal Compatible Process Media
Water; Oil; Gases; Liquids and Gases Compatible with Brass and Buna-N Rubber
Liquid-Filled Case
Yes
Seal Diaphragm Material
Buna-N
Movement Material
Copper Alloy
Seal Fill Liquid
Instrument Oil
Movement Type
Swiss
Seal Lower Housing Material
Brass
Nominal Dial Size
2 1/2 in
Sensor Material
Copper Alloy
Pointer Material
Aluminum
Sensor Type
Bourdon Tube
Pressure Gauge Type
Industrial Pressure Gauge with Diaphragm Seal
Standards
ANSI/ASME B40.1
Product Description
This gauge features plastic case construction to resist corrosion and impact in demanding applications.
Expertly Selected Product Pairings
Compliance & Restrictions
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Item Barcode
Pressure Gauge,Filled,600 Psi,
| Name | Item | Description | |
|---|---|---|---|
 | Grainger Dropship | 5NMY5 | Pressure Gauge,Filled, |
 | UNSPSC CODES | 41112403 | |
 | VMRS (ATA) CODES | 053-006-009 | Pressure Gauge,Filled, |
