ZOELLER

Sewage Ejector Pump, HP 1/2, Flow Rate at 10 Ft. of Head 85.0 gpm, Discharge 2" FNPT

Hover over image to magnify
Pump,Sewage,1/2 Hp
PI_Asset_969151
Pump,Sewage,1/2 Hp
PI_Asset_969151
Sewage Ejector Pump, HP 1/2, Flow Rate at 10 Ft. of Head 85.0 gpm, Discharge 2" FNPT Video

#911919-7 | Pkg Qty: 1

$781.93 pkg | $781.93 ea

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Agency Compliance
UL Listed, CSA Certified
Maximum Temperature (Deg. F)
130
Amps
10.4 A
Mfr. Part Number
N267
Base Material
Cast Iron
Mfr. Warranty Length
3 yr.
Bearing Type
Oil Lubricated
Motor RPM
1725
Brand
ZOELLER
Motor Type
Hermetically-Sealed, Oil-Filled
Cord Length
15 ft.
Package Quantity
1
Diameter
13-1/16 in.
Phase
1
Discharge NPT
2 in.
Pump Body Material
Cast Iron
GPM of Water @ 10 Ft. of Head
89
Pump HP
1/2
GPM of Water @ 15 Ft. of Head
50
Pump Type
Manual
GPM of Water @ 20 Ft. of Head
10
RPM
1725
GPM of Water @ 5 Ft. of Head
128
Shaft Material
Carbon/Ceramic
Height
14-9/32 in.
Shaft Seal
Carbon/Ceramic
Horsepower
1/2
Shaft Seal Material
Carbon, Ceramic
Housing
Cast Iron
Shipping Weight
46.4 lb.
Housing Material
Cast Iron
Switch Type
None
Impeller Material
Polypropylene
Thermal Protection
Yes
Input Phase AC
1
Top Material
Cast Iron
Item
Submersible Sewage Pump
Type
Manual
Maximum Diameter Solids
2 in.
Voltage
120 VAC
Maximum Head
20 ft.
Warranty
1 yr.
Maximum Liquid Temperature
130°F
General
Body Dia.
13 1/16 in
Nominal Voltage
110V AC
Discharge Dia.
2 in
Phase - Pumps
1
Discharge Gender
Female
Rated Voltage
115V AC
Discharge Standard
NPT
Shaft Seal Material - Pumps
Carbon, Ceramic
Flow Rate @ 10 Ft. of Head
85 gpm
Standards
CSA Certified
Flow Rate @ 15 Ft. of Head
45 gpm
Switch Actuation
No Switch Included
Flow Rate @ 20 Ft. of Head
10 gpm
Switch Electrical Connection
No Switch Included
Min. Sump Pit Dia.
18 in

Product Description

These general purpose 110 to 120V sewage ejector pumps remove sewage containing solids from drains where a gravity system won't work, such as in septic systems that are below the main sewer line. They are compatible with most standard U.S. residential electrical wall outlets and have a Type A (two prongs, ungrounded) or Type B (three prongs, grounded) power cord plug.
