BUSSMANN

Bussmann 1-Pole Limiter Fuse Block, AC: 125VAC, DC: 80VDC, 10 to 800A, Series ANN, ANL

Hover over image to magnify
Limiter Fuse Block
PI_Asset_927383
PI_Asset_927384
Limiter Fuse Block
PI_Asset_927383
PI_Asset_927384
Double tap image to magnify
Limiter Fuse Block
9116052_1
9116052_2
Limiter Fuse Block
9116052_1
9116052_2

#911605-2Pkg Qty: 1

$54.97 pkg | $54.97 ea

In Stock

Shipping to 43085
Expected to arrive Wed. Mar 26.
|

Technical Specifications

Key Specifications
AC Voltage Rating
125 VAC
Fuse UL Class
Not Class Rated
Amp Range of Fuse Block or Holder
10 to 800A
Height
1.62 in.
Amperage Range
10-800 A
Item
Fuse Block
Body Material
Thermoplastic
Length
3.37 in.
Brand
BUSSMANN
Maximum Amps
800
DC Voltage Rating
80 VDC
Maximum Voltage
125 V
For Fuse Series
ANN, ANL
Mfr. Part Number
4164
For Fuse Size
3-3/16 in. L x 7/8 in. dia
Mounting Style
Bolt Down
Fuse Block Design
Open
Number of Poles
1
Fuse Block/Fuse Holder Type
Fuse Block
Package Quantity
1
Fuse Block/Holder AC Voltage Rating
125 VAC
Series
4164
Fuse Block/Holder DC Voltage Rating
80 VDC
Shipping Weight
.15 lb.
Fuse Dimensions
3-3/8 in.L x 1 in. W x 1-5/8 in. H
Voltage Rating
125 VAC/80 VDC
Fuse Holder Code
X
Width
1 in.
Fuse Type
Limiter
General
Amp Range
10 to 800 A
Fuse Block or Fuse Holder Type
Fuse Block
Compatible Fuse Series
ANL, ANN, CNL, CNN
Fuse Block or Holder AC Voltage Rating
125VAC
Fits Fuse Type
Limiter
Fuse Block or Holder DC Voltage Rating
80VDC
For Use With
ANL and ANN Fuses
Visual Indication
Nonindicating
Fuse Block Style
Nonrejection

Product Description

These fuse blocks are compatible with forklift limiter fuses that provide overcurrent protection for the electrical systems of lift trucks, scissor lifts, pallet movers, and other heavy-duty battery-powered equipment. They hold flat-body series ANL, CNL, ANN, and CNN fuses, which are used in limited-space installations.

Automotive and fleet fuses boxes hold fuses that provide overcurrent protection in DC-powered vehicles and equipment such as cars, forklifts, and battery-powered systems. They have an open top for access to fuses, clips or studs for securing fuses within the block, and terminals for connecting to the circuit.

Documents

Bussmann 4164 and 4164-FR Fuse Block Data Sheet
