PHILIPS ADVANCE

Philips Advance Electronic Ballast, 54 Max. Lamp Watts, 120-277 V, Programmed Start, No Dimming

Hover over image to magnify
Electronic, Ballast, 120V
PI_Asset_948240
Electronic, Ballast, 120V
PI_Asset_948240
Philips Advance Electronic Ballast, 54 Max. Lamp Watts, 120-277 V, Programmed Start, No Dimming Video
Philips Advance Electronic Ballast, 54 Max. Lamp Watts, 120-277 V, Programmed Start, No Dimming Video

#911309-2 | Pkg Qty: 1

$52.25 pkg | $52.25 ea

Drop Ship Item

Shipping to 60045
|

Technical Specifications

Key Specifications
Amps AC
1.00 to 0.43
Length
14-3/16 in.
Ballast Family
Centium
Light Output
Normal
Ballast Type
Electronic
Mfr. Part Number
ICN-2S54-T
Brand
PHILIPS ADVANCE
Number of Lamps
2
Dimming
No
Package Quantity
1
Dimming Type
No Dimming
Shipping Weight
1.1 lb.
Height
1-1/16 in.
Start Type
Programmed
Item
Fluorescent Ballast
Voltage
120/277
Lamp Type
T5 Lamps
Width
1-3/16 in.
Lamp Watts
54 W
General
Ballast Bulb Type
T5HO
Number of Bulbs Supported
1, 2
Ballast Factor
1
Number of F54T5 Lamps
1 or 2
Ballast Start Type
Programmed
Number of FC12T5 Lamps
1 or 2
Brand and Series
Centium(TM)
Operating Amps @ 120V
0.83 A
Dimming Method
No Dimming
Power Factor
0.98
Dimming Range
No Dimming
Total Harmonic Distortion
Less Than 10%
Max. Bulb Watts
54 W
Wiring Type
Series
Min. Starting Temp.
-20 Degrees F

Product Description

Programmed rapid-start electronic fluorescent ballasts turn on lights near-instantaneously. They are more energy efficient and less damaging to fluorescent light bulbs than instant-start ballasts and rapid-start ballasts. They are used in lighting fixtures that will be turned on or off frequently via occupancy sensors and other lighting controls that automatically operate the lights. The ballasts provide a small amount of voltage to preheat the bulbs' filaments before the bulbs turn on. This small initial voltage is supplied for a specific amount of time to avoid glow current, which can damage the light bulbs.
