Self-adjusting tensioner: A V-Belt Size Range, 3" Idler Outside Dia., 1 1

Name: Self-adjusting tensioner: A V-Belt Size Range, 3" Idler Outside Dia., 1 1
Brand: FENNER DRIVES
SKU: 9104343
Price: 143.83 USD
Availability: InStock

Hover over image to magnify

Double tap image to magnify

#910434-3Pkg Qty: 1

$143.83 pkg | $143.83 ea

In Stock

Shipping to 43085

Expected to arrive Fri. Apr 04.

Technical Specifications

Key Specifications

Application

V-Belt Drives

Function

Self-Adjusting Tensioner Eliminates Need For Regular Manual Retensioing

Brand

FENNER DRIVES

Insert

Alloy Steel, Accurately Wound Compression Springs Are Used To Provide Consistent Tensioning Force

Dimension A

1.67 in.

Item

Self-Adjusting Tensioner

Dimension B

0.28 in.

Mfr. Part Number

FS0127

Dimension C

0.91 in.

Mounting Hole

2/5 in.

Dimension D

2.76 in.

Package Quantity

Dimension E

6.39 in.

Shipping Weight

1.2 lb.

Dimension G

0.41 in.

V-Belt Size Range

Dimension T

1.17 in.

General

Arm Material

Aluminum

Maximum Tension Force

30 lbf

Arm Rotation

45 Degrees

Minimum Tension Force

0 lbf

Base Diameter

2.76 in

Mount Hole Diameter

13/32 in

For V-Belt Size

Overall Depth

1.67 in

Product Description

Self-adjusting tensioner, - ANSI Chain Size, A V-Belt Size Range, Idler Outside Dia. 3.0 in, Mounting Hole2/5 in, Mounting Hole (Metric), Idler Bolt-, Temp. Range (F) 32 to 225, Force Range (Lbs.) 0 to 30, Normal 10 Deg. Force (Lb.), Hard 10 Degree Force (Lb.), -, Hard 20 Degree Force (Lb.), Normal 20 Deg. Force (Lb.), -, Hard 30 Degree Force (Lb.), Normal 30 Deg. Force (Lb.), -
