Steel Hex Pipe Reducing Nipple 1/4 in. x 1/8 in.

Hover over image to magnify
Steel Hex Nipple 1/4X1/8
Steel Hex Nipple 1/4X1/8

#97075 | Pkg Qty: 10

In Stock

Shipping to 60045
|
Catalog: F10

Technical Specifications

Brand
APPROVED SUPPLIER
Fitting Style
Hex Nipple
Eaton/Aeroquip Cross
2083-4-2S
Hex Size
5/8
Fitting Connection (A) Gender
Male
Mfr. Part Number
97075
Fitting Connection (A) Pipe Size
1/4 in.
Package Quantity
10
Fitting Connection (A) Pipe Thread Size
1/4-18
Plating
Clear Trivalent
Fitting Connection (A) Style
NPTF Pipe
Pressure Connection Cross
5404-04-02
Fitting Connection (B) Gender
Male
Shipping Weight
.55 lb.
Fitting Connection (B) Pipe Size
1/8 in.
System of Measurement
Fractional
Fitting Connection (B) Pipe Thread Size
1/8-27 in.
Temperature Range (Deg. F)
-65 to +400 deg. F
Fitting Connection (B) Style
NPTF Pipe
Vibration Resistance
Fair
Fitting Material
Steel
Weatherhead Cross
C3069X4X2

Product Description

  • Typical Applications:
  • Gasoline, instrumentation, power steering, air brake, pneumatic, diesel, propane, and natural gas lines.
  • It is recommended to always use thread sealant or tape on tapered pipe threads.
  • Tapered pipe thread seal on wedging contact between threads. The more you tighten the tighter the seals.
  • Pipe threads are the most common fitting style used in the United States and Canada.
  • The difference between NPT and NPTF is the root and crest tolerances.
  • Imperial pipe fittings are made to NPTF (National Pipe Thread Fuel) specifications.
Item Barcode
0970750
Steel Hex Nipple 1/4X1/8
 NameItemDescription
WEATHERHEADWEATHERHEADC3069X4X2STL HEX NIP C3069X4X2
UNSPSC CODESUNSPSC CODES40170000Pipe piping and pipe fittings
VMRS (ATA) CODESVMRS (ATA) CODES053-008-004STL PIPE HP C3069X4X2
