HALDEX
Haldex 3030 Long Stroke Combination Spring Brake - GL3030L
Hover over image to magnify
Technical Specifications
Air Port Thread
3/8-18 NPTF
Pushrod Thread
5/8-18 UNF
Available Stroke
3 in.
Shipping Weight
21.76 lb.
Brand
HALDEX
Stud Grade
5
Item
Spring Brake
Stud Length
1-1/2 in.
Maximum Air Pressure
150 psi
Stud Spacing
4-3/4 in.
Mfr. Part Number
GC3030L
Stud Type
5/8-11 UNC
Package Quantity
1
Product Description
Haldex® Gold Seal Air Brake Actuator
- Combination Actuator - 3030 Long Stroke
- Superior Power Spring Technology: Advanced Powder Coating For Corrosion Restistance
- Double O-Ring Centerseal: Positive Sealing And Plastic Bearings For Long Life
- Superior Diaphragm: High Quality Rubber Compound Resists Heat And Cold, Flexible Even At -40°F
- Rugged Service Housing: 9 Gauge Powder Coated Steel
- Maximum Air Pressure: 150 Psi
Item Barcode
Haldex Combo Ab Act 3030 Long
| Name | Item | Description | |
|---|---|---|---|
 | UNSPSC CODES | 25171700 | |
 | VMRS (ATA) CODES | 013-004-027 | COMBO AB ACT 3030 LONG |
